RB900L3

PROGRAMMABLE 2G/3G/4G Cat. 1 TERMINAL

The RB900L3 terminal series is the complete modem solution for wireless m2m applications. Based on the high quality module, it offers high level LTE features in compact aluminum housing with all the standardized interfaces. Together with its small size and wide supply voltage range, makes it easy to integrate into all kinds of machines.

The RB900L3 terminal enabling high speed data transmission, SMS e-mail, TCP/UDP/PPP communication is a universal solution for all low-volume M2M and mobile data applications including metering, traffic systems, transportation and logistics, security, vending machines, and facility management.

Device can be controlled by standard AT commands thus making it the smallest, complete SMT platform for M2M solutions.

Mobile• 2G, 3G and LTE Cat. 1 support
Communication protocols• RS232
• USB
System• Control via AT commands or „C” application
• Telit AT command set
• Embedded TCP/lP and UDP stacks, LwM2M
• AppZone „C” language
• LwM2M, simWISE
Function• SMS, TCP/IP, UDP
Power supply• 5 to 30V DC
Dimensions• 83 x 53.3 x 26 mm
Housing• rugged metal
Warranty• 24-months
