NTS-3000
NTP/PTP IEEE1588 Network Time Server
NTS-3000 is a grandmaster PTP/IEEE1588 and NTP Stratum-1 Network Time Server. Optionally it can be equipped with TCXO* or OCXO* holdover oscillator. The oscillator guarantees precision time for period of missing GNSS satellite signals. Standard configuration includes 2x 100Mbps on LAN1-2. The NTS-3000 supports 2x redundant GNSS receiver and has redundant* power supplies option. The sync I/O is 1PPS-input only to connect external freq. ref. This device is suitable for critical infrastructure support. It has uptime counted in years.
- NTP Time Server STRATUM1
- IEEE1588 PTP & NTP
- LAN1-2 => 100/10Mbps
- 2x redundant GNSS receiver inputs ANT1&2.
| Model NTS-3000 | • Grandmaster PTP/IEEE1588 and NTP Stratum-1 Network Time Server |
|---|---|
| Interfaces | • 2x LAN Ethernet 100Base-T (RJ45) • 2x Antenna INPUT or OUTPUT (RJ45) • 2x USB 2.0 (for firmware upload) • 1x RS232C (D-SUB9) |
| Holdover OSC | • Optionally with TCXO* or OCXO* holdover oscillator |
| sync PROTOCOL | • NTP, SNTP, PTP IEEE1588 |
| Management | • SNMP (v1,2,3), MIB2, RADIUS, HTTP, HTTPS, SSH, TELNET, NTPQ/NTPDC |
| NTP | • NTP v2, v3, v4 LAN1-2: • RFC1305, RFC1119, RFC5905, RFC5906 • RFC5907, RFC4330, RFC2030 |
| SNTP | • SNTP v2, v3, v4 LAN1-2: • RFC4330 • RFC2030 |
| DAYTIME* Protocol | • RFC867 • RFC868 |
| Perfomance | • GNSS 1PPS-in @ 2-sigma/<5ns • Network performance > 10000 req/s • Max. councurrent NTP clients 9.2 mln |
